Powerful V2X
Onboard Unit

  • Improved connectivity
    (DSRC / ETSI-G5, C-V2X)
  • Small form factor
  • High-precision positioning
  • Intelligent power management
  • Tamper-proof and secure
  • Rapid startup times
  • Easy integration
  • Audio and video notifications
  • Reduced custom app
DETAILS
The fourth generation of Commsignia’s vehicular connectivity system offers superior performance coupled with the V2X Software stack. The unit enables low-cost and easy OEM or aftermarket integration, offering a built-in Tamper-proof Hardware Security Module, CAN, high-range V2X radio, and easy HMI integration. By combining the benefits of automotive-grade design, a high-performance application CPU and dual-channel V2X radio performance, the ITS-OB4 offers a professional, complete, and future proof solution.

COMPETITIVE FEATURES

  • Dedicated next-generation V2X chipset
  • Dual-channel operation
  • Automotive-grade design
  • Extended radio coverage with a single unit
  • Complete real-time V2X Stack
    (ETSI, IEEE, SAE, ISO)
  • Available with Autotalks / NXP / Marvell / Qualcomm 9150 V2X chipset
  • Powerful application CPU
  • Fine-tuned system startup process

EASY INTEGRATION

  • CAN and other sensor inputs
    (Camera, Radar, LiDAR)
  • High frequency GNSS,
  • High precision positioning
  • Flexible Management Tool
  • Statistics and Reports
  • Video/Audio interface

DEVELOPMENT AND SUPPORT

  • Software Development Kit: Linux and RTOS available for normal and time critical application development
  • Multi-level Technical Support
  • Regular Software Upgrades
  • User & Programmer’s guide
  • Available APIs: native C / remote C / remote Java / remote ASN.1
  • Sample Applications

COMPLETE SECURITY AND SUPERVISION

  • Tamper protected, supervised system
  • Support for future security upgrade
  • Cryptographic Acceleration for V2X
  • Tamper proof certificate storage (HSM)
  • USDOT SCMS / EU PKI compatible
Architecture
TECHNICAL SPECIFICATIONS

Core Features

CPU800MHz Freescale/NXP i.MX 6
OSLinux / RTOS (V2X)
RAM2 GB DDR3 SDRAM
Flash4 GB eMMc
StorageDual micro SD Card slot
Ethernet10/100/1000 Mbps Ethernet
External I/ODual USB 2.0, GPIO
SupervisorYes
Power supply8-32 VDC (surge and reverse polarity protected)
Backup powerYes (10s Store & Shutdown) (optional)
PositioningAdvanced GNSS
WifiDual band a/b/g/n Mini PCIe slot #1 only (optional)
BluetoothYes (optional)
Cellular3G / LTE (MiMo) Mini PCIe slot #2 only
IMU3 axis gyroscope BOSCH
3 axis accelerometer BMI160
3 axis magnetometer BMM150

Connectors

Antenna2 x V2X, 2 x WiFi, 2 x LTE/3G, 1 x GNSS
Data1 x ETH, 2 x USB, 1 x CAN, 1 x OBD-II
OtherPower connector
Reset button
4 x Bicolor LEDs
Extension2 x Mini PCIe slots
VideoHDMI 1.4a
Line out3.5mm jack

Available V2X Radio Variants

Autotalks Secton
NXP TEF5100 (RF Transceiver) & SAF5100 (Baseband)
Marvell SDIO (88W8987PA)
Qualcomm 9150

Security

Hardware Security Module (HSM) SLI97
ECDSA verification (> 2000 verifications),
ECDSA encryption (< 50 usec signing delay)
NIST and Brainpool verification, encryption
Secure boot, encrypted storage, tamper proof system
EAL6+ certified and available with
up to 1MB of secure SOLID FLASH
ARM TrustZone including the TZ architecture

Environmental

Operation humidity: 10% ~ 95%
Storage humidity: max 95%
Temperature range: -40C ~ +85C
Vibration proof

V2X Integration

Over the years, Commsignia has gained a tremendous amount of experience in deploying and operating V2X onboard units.

  • Participating in deployment and OEM/Tier-1 trials
  • Fusion algorithms for ADAS systems
  • Day1 / Day2 applications
  • Sensor data integration

Complete Ecosystem with V2X Software

The Commsignia V2X Software Stack is a flexible embedded solution developed based on the specification of the ISO / ETSI / IEEE / SAE / C2C-CC communication architecture. The software stack provides a modular framework and small footprint for various resource-constrained target platforms, supporting Linux and RTOS operating systems.

MEET THE SOFTWARE
WHO IS IT FOR?
Use Cases
Electronic Emergency Brake Light

The vehicle broadcasts an emergency brake event to nearby vehicles. The recipient vehicles determine the relevance of the information and warn the drivers about the event if appropriate.
Stationary vehicle warning

Informs road users about a stationary vehicle before they could actually see it to eliminate the risk of accidents.
Forward Collision Warning

Warns drivers about an impending rear-end collision with another vehicle in the traffic in the same lane.
Intersection Movement Assist

A vehicle-to-vehicle (V2V) application that warns the driver when it’s not safe to enter an intersection.
Emergency vehicle

Prepares the driver to give way to an approaching emergency vehicle before its presence could be realized.
Lane Change Assist

Assists a vehicle in changing lanes, and sends a warning signal to the driver if the intended lane destination is occupied by other vehicles.
